C18661 Copper-Magnesium (CMG1) Alloy Wire
Download PDF
Copper-magnesium is a solid solution alloy providing high strength with nominal reduction in conductivity relative to copper. CMG1 is one of the alloys covered by the broad CDA alloy designation C18661 for copper-magnesium. CMG1 combines high electrical conductivity with good tensile strength, excellent solderability and plateability. Applications include connectors, semiconductor pins, catenary trolley cables and conductors. There are no ASTM developed temper ranges for this alloy and the listed values are the recommendations of Fisk Alloy Wire.
Mechanical Properties
Round Wire
| Temper Name | Temper Code | Tensile Strength (N/mm²) | Mill Limits | |
| Min | Max | |||
| Annealed | 240 | 315 | .0254 - 3.264 mm | |
| 1/2 Hard | H02 | 380 | 485 | |
| Hard | H04 | 515 | 620 | |
| Spring | H08 | 620 | 0 | |
Square Wire
| Temper Name | Temper Code | Tensile Strength (N/mm²) | Mill Limits | |
| Min | Max | |||
| Annealed | 240 | 315 | .2540 - 1.905 mm | |
| 1/2 Hard | H02 | 380 | 485 | |
| Hard | H04 | 515 | 620 | |
| Spring | H08 | 620 | 0 | |
Physical Properties
| Melting Point (Liquidis) | 1070°C |
| Melting Point (Solidus) | 1010°C |
| Density | 8.8854 gm/cu cm |
| Electrical Resistivity (Annealed) | 2.344 ?? -cm @ 20°C |
| Electrical Conductivity (Annealed) | 0.429 MegaSiemens /cm @ 20°C |
| Coefficient of Thermal Expansion | 0.00001764°C (20-300°C) |
| Modulus of Elasticity (Tension) | 32625 MPa |
For a full size version of product specifications, including chemical composition in both US and Metric units, please download the PDF.
