MicroShield® Conductor Wire

Download PDF

Micro Shield, an alternative to stainless steel shielding, was engineered specifically for high strength coaxial shielding applications. It is a copper-nickel-tin alloy processed for both high strength and long flex life.

Key Attributes of Micro Shield

  • Strong with tensile strengths in excess of 150,000 psi (1030 MPa or 105 kg/mm squared).
  • Highly solderable
  • Excellent resistance to corrosive environments.
  • Has identical chemical, mechanical and electrical properties to CS-95.

Micro Shield is available bare or electroplated with nickel, silver or tin. And, in ultra-find gauges as single end wires or as multiple wire bobbins.

English UnitsMetric Units

Physical Properties

Hard Drawn
Tensile 1034 MPa
Elongation 1%
Electrical Conductivity 0.058 megmho/cm @ 20°C
Electrical Resistivity 2.362 microhm-cm @ 20°C
Melting Point 1060°C
Density 8.89 g/cm³

Single End Constructions

Hard Temper: bare or plated with nickel, silver, or tin
 AWG Diameter (mm) Resistance
(Ω/km)		 Weight
(kg/km)		 Break StrG
(N)
Min Max Max Max Min
34 0.1575 0.1626 8,852 0.1845 20.2
35 0.1397 0.1448 11,247 0.1463 15.8
36 0.1245 0.1295 14,170 0.1171 12.6
37 0.1118 0.1168 17,575 0.0952 10.1
38 0.0991 0.1041 22,372 0.0757 7.96
39 0.0864 0.0914 29,432 0.0583 6.05
40 0.0762 0.0813 37,805 0.0461 4.72
41 0.0686 0.0737 46,673 0.0378 3.82
42 0.0610 0.0660 59,071 0.0305 3.02
43 0.0533 0.0584 77,155 0.0238 2.31
44 0.0483 0.0533 94,254 0.0198 1.89
45 0.0422 0.0472 123,476 0.0156 1.45
46 0.0373 0.0424 157,459 0.0125 1.13
47 0.0330 0.0381 201,333 0.0101 0.885
48 0.0290 0.0340 261,811 0.0080 0.681
49 0.0257 0.0307 333,549 0.0065 0.534
50 0.0226 0.0277 429,555 0.0054 0.414



Hard Temper; bare or plated with nickel, silver, or tin

For a full size version of product specifications, including chemical composition in both US and Metric units, please download the PDF.
