Percon® 28 Conductor Wire
Download PDFPercon 28 is engineered to have 33% greater minimum break strength with the same electrical conductivity of ASTM B 624 conductors. This alloy allows wire and cable system designers performance improvements in strength, flex life, and the ability to reduce finish cable gauge sizes, saving weight while sustaining the cable break strength of a larger gauge size.
Key Attributes of Percon 28
- RoHS complaint; does not contain cadmium or any environmentally hazardous elements.
- Exceptional flex life.
- Highly resistant to thermal softening from high operating or fluoropolymer insulating temperatures.
- Exhibits the nobility inherent in all high copper alloys and is therefore resistant to corrosive environments.
Percon 28 is available in bare, silver or nickel plated and in light weight constructions.
Physical Properties
Tensile | 552 MPa |
Elongation | 6% |
Electrical Conductivity | 0.493 megmho/cm @ 20°C |
Electrical Resistivity | 2.028 microhm-cm @ 20°C |
Melting Point | 1078°C |
Density | 8.94 g/cm³ |
Thermal Coefficient of Resistance | 0.00342 Per °C |
Alloy Characteristics
7-Strand Constructions
SILVER PLATED PERCON 28 (MINIMUM 40 MICRO-INCH SILVER THICKNESS) | |||||||
AWG | CONST | PLATE % | DIAMETER (mm) | RESISTANCE (Ω/km) |
WEIGHT (kg/km) |
BREAK STR (N) |
|
MIN | MAX | MAX | MAX | MIN | |||
22 | 7/0.254 | 2 | 0.754 | 0.770 | 59.1 | 3.29 | 192 |
24 | 7/0.203 | 2.5 | 0.602 | 0.617 | 92.8 | 2.12 | 122 |
26 | 7/0.160 | 3 | 0.472 | 0.488 | 151 | 1.32 | 75.2 |
28 | 7/0.127 | 4 | 0.373 | 0.392 | 244 | 0.855 | 47.0 |
30 | 7/0.102 | 5 | 0.297 | 0.315 | 385 | 0.555 | 29.8 |
32 | 7/0.0787 | 6.1 | 0.229 | 0.244 | 644 | 0.332 | 17.6 |
34 | 7/0.0635 | 8 | 0.183 | 0.198 | 1006 | 0.220 | 11.3 |
36 | 7/0.0508 | 10 | 0.145 | 0.160 | 1605 | 0.144 | 7.06 |
38 | 7/0.0399 | 10 | 0.114 | 0.125 | 2681 | 0.0915 | 4.23 |
40 | 7/0.0315 | 10 | 0.090 | 0.099 | 4457 | 0.0592 | 2.54 |
42 | 7/0.0251 | 10 | 0.072 | 0.079 | 7313 | 0.0392 | 1.55 |
44 | 7/0.0198 | 10 | 0.056 | 0.062 | 11174 | 0.0233 | 1.01 |
46 | 7/0.0157 | 10 | 0.045 | 0.050 | 17830 | 0.0148 | 0.64 |
NICKEL PLATED PERCON 28 (MINIMUM 50 MICRO-INCH NICKEL THICKNESS) | |||||||
AWG | CONST | PLATE % | DIAMETER (mm) | RESISTANCE (Ω/km) |
WEIGHT (kg/km) |
BREAK STR (N) |
|
MIN | MAX | MAX | MAX | MIN | |||
22 | 7/0.254 | 2 | 0.754 | 0.770 | 60.4 | 3.27 | 192 |
24 | 7/0.203 | 2.5 | 0.602 | 0.617 | 96.8 | 2.11 | 122 |
26 | 7/0.160 | 3 | 0.472 | 0.488 | 160 | 1.32 | 75.2 |
28 | 7/0.127 | 4 | 0.373 | 0.389 | 257 | 0.835 | 47.2 |
30 | 7/0.102 | 5 | 0.297 | 0.312 | 417 | 0.540 | 29.8 |
32 | 7/0.0787 | 6.1 | 0.229 | 0.244 | 705 | 0.329 | 17.6 |
19-Strand Unilay Constructions
SILVER PLATED PERCON 28 (MINIMUM 40 MICRO-INCH SILVER THICKNESS) | |||||||
AWG | CONST | PLATE % | DIAMETER (mm) | RESISTANCE (Ω/km) |
WEIGHT (kg/km) |
BREAK STR (N) |
|
MIN | MAX | MAX | MAX | MIN | |||
18 | 19/0.254 | 2 | 1.186 | 1.234 | 21.1 | 9.12 | 531 |
20 | 19/0.203 | 2.5 | 0.947 | 0.995 | 35.1 | 5.90 | 340 |
22 | 19/0.160 | 3 | 0.743 | 0.791 | 57.4 | 3.71 | 211 |
24 | 19/0.127 | 4 | 0.587 | 0.621 | 93.2 | 2.325 | 130 |
26 | 19/0.102 | 5 | 0.466 | 0.502 | 147 | 1.510 | 82.4 |
28 | 19/0.0787 | 6.1 | 0.359 | 0.383 | 238 | 0.904 | 47.8 |
30 | 19/0.0635 | 8 | 0.288 | 0.312 | 371 | 0.599 | 30.6 |
32 | 19/0.0508(1) | 10 | 0.241 | 0.267 | 592 | 0.392 | 19.2 |
34 | 19/0.0399(1) | 10 | 0.191 | 0.208 | 990 | 0.249 | 11.5 |
(1) True Concentric |
NICKEL PLATED PERCON 28 (MINIMUM 50 MICRO-INCH NICKEL THICKNESS) | |||||||
AWG | CONST | PLATE % | DIAMETER (mm) | RESISTANCE (Ω/km) |
WEIGHT (kg/km) |
BREAK STR (N) |
|
MIN | MAX | MAX | MAX | MIN | |||
18 | 19/0.254 | 2 | 1.186 | 1.210 | 22.3 | 8.91 | 520 |
20 | 19/0.203 | 2.5 | 0.947 | 0.971 | 35.7 | 5.73 | 331 |
22 | 19/0.160 | 3 | 0.743 | 0.767 | 59.2 | 3.58 | 204 |
24 | 19/0.160 | 4 | 0.587 | 0.612 | 94.8 | 2.28 | 128 |
26 | 19/0.102 | 5 | 0.467 | 0.490 | 155 | 1.469 | 81.0 |
28 | 19/0.0787 | 6.1 | 0.361 | 0.384 | 261 | 0.894 | 47.6 |
For a full size version of product specifications, including chemical composition in both US and Metric units, please download the PDF.
