C172 Beryllium Copper Alloy Wire (CuBe2)
Download PDFBeryllium Copper alloys combine form-ability with very high strength properties when aged. Applications are in springs, connectors, switches and automotive parts. Special heat treating of the wire at the mill produces a “Mill Hardened” (HM) tempered Beryllium Copper wire which can then be formed and used without additional heat treatment.
Mechanical Properties
Round Wire
Temper Name | Temper Code | Tensile Strength (N/mm²) | Mill Limits | |
Min | Max | |||
Annealed (A) | TB00 | 400 | 540 | .0254 - 3.264 mm |
1/4 Hard | TD01 | 620 | 795 | |
1/2 Hard | TD02 | 760 | 930 | |
3/4 Hard | TD03 | 895 | 1070 | |
Hard | TD04 | 965 | 1140 | |
AT | TF00 | 1105 | 1380 | |
1/4 HT | TH01 | 1205 | 1450 | |
1/2 HT | TH02 | 1275 | 1480 | |
3/4 HT | TH03 | 1310 | 1585 | |
HT | TH04 | 1345 | 1585 |
Square Wire
Temper Name | Temper Code | Tensile Strength (N/mm²) | Mill Limits | |
Min | Max | |||
Annealed (A) | TB00 | 400 | 540 | .2540 - 1.905 mm |
1/4 Hard | TD01 | 620 | 795 | |
1/2 Hard | TD02 | 760 | 930 | |
3/4 Hard | TD03 | 895 | 1070 | |
Hard | TD04 | 965 | 1140 | |
AT | TF00 | 1105 | 1380 | |
1/4 HT | TH01 | 1205 | 1450 | |
1/2 HT | TH02 | 1275 | 1480 | |
3/4 HT | TH03 | 1310 | 1585 | |
HT | TH04 | 1345 | 1585 |
Rolled Flat
Temper Name | Temper Code | Tensile Strength (N/mm²) | Mill Limits | |
Min | Max | |||
Annealed (A) | TB00 | 415 | 540 |
Thickness: Width:
|
1/4 Hard | TD01 | 515 | 605 | |
1/2 Hard | TD02 | 585 | 690 | |
Hard | TD03 | 690 | 895 | |
AT | TF00 | 1140 | 1345 | |
1/4 HT | TH01 | 1205 | 1415 | |
1/2 HT | TH02 | 1275 | 1480 | |
HT | TH03 | 1310 | 1515 |
Physical Properties
(1) Expressed as a range per CDA | |
Melting Point (Liquidis) | 982°C |
Melting Point (Solidus) | 866°C |
Minimum Solutionizing Temperature | 788°C |
Density | 8.24871 gm/cu cm |
Electrical Resistivity (Annealed) | 7.6804 ?? -cm @ 20°C |
Electrical Conductivity (Age Hardedned) | 0.12879 MegaSiemens /cm @ 20°C |
Thermal Conductivity (Solutionized-Aged) | (1) 107-130 W/m · °K @ 20°C |
Coefficient of Thermal Expansion | 0.00001782°C (20-300°C) |
Modulus of Elasticity (Tension) | 127600 Mpa |
Modulus of Rigidity | 50300 Mpa |
For a full size version of product specifications, including chemical composition in both US and Metric units, please download the PDF.
